SmallRig Cage Kit for Sony Alpha 7C II / Alpha 7CR 4422 is designed to attach accessories and protect the camera and HDMI port. It includes a cage and a HDMI cable clamp. The cage secures the camera firm via one 1/4"-20 screw on the bottom and one M2.5 screw on the right side, with built-in cushions preventing scratches. Its hinge arm at the battery door better fits the camera curve and leaves room for the pinkie for more comfort. The HDMI cable clamp quickly attaches to the left side of the cage by using a thumb screw, protecting the HDMI port to ensure stable transmission. Comes with multiple mounting points for attaching accessories, including 1/4"-20 threaded holes and ARRI 3/8"-16 locating holes for Top Handle 3765, Side Handle 2913; one top ARRI 3/8"-16 locating hole for Monitor Mount 2903B; cold shoes for microphone, LED video light; a NATO rail for Rotating NATO Handle (Left Side) 3260; Built-in M4 threaded holes on the bottom front, compatible with Horizontal-to-Vertical Mount Plate 4424, realizing fast switching between vertical and horizontal shooting; and a bottom QD socket for mounting shoulder straps. The Arca Swiss quick-release plate on the bottom supports DJI RS 2 / RSC 2 / RS 3 / RS 3 Pro gimbals as well as DJI RS 2 / RSC 2 gimbals’ quick-release plate and Arca-Type Quick Release Plate 3154. The cage also reserves holes on both sides and the bottom for attaching accessories like Hand Strap 3848, Shoulder Strap PSC2428, etc. Besides, a magnetic Allen wrench is included for easy disassembly and assembly.
1. An all-in-one full cage that protects the camera.
2. Featured an added hinge arm at the battery door to fit the camera curve and improve the handgrip feeling.
3. HDMI cable clamp protects ports for stable transmission and allows quick assembly & disassembly via a thumb screw.
4. Locks camera via one 1/4"-20 screw and one M2.5 screw.
5. Features an Arca Swiss quick-release plate on the bottom for fast switching between handheld, tripods, or DJI RS 2 / RSC 2 / RS 3 / RS 3 Pro gimbals shooting modes.
Note:
1. Please remove the strap ring on the right side of the camera before installing the cage. Please refer to the user manual for installation.
2. If you need to use the camera's headphone jack, you need to remove the HDMI Cable Clamp first.
Work With Sony Alpha 7C II, Sony Alpha 7CR
Cage x 1
HDMI Cable Clamp x 1
User Manual x 1
Product Dimensions: 142 x 93 x 56.4mm
Package Dimensions: 161 x 123 x 71.5mm
Product Weight: 152±5g
Package Weight: 238.5±5g
Material(s): Aluminum Alloy, Stainless Steel
