Portkeys PT5 II 5 Inch 4K HDMI Touchscreen Monitor

PT5 II is an entry-level monitor for filmmakers looking for a compact on-camera display. The PT5 II features a 10 bit 5-inch 1920 x 1080 display with a 500nit brightness and 1000:1 contrast ratio. PT5 II housing with additional heat sink holes. This monitor is much more affordable. Compact, durable, and lightweight, PT5 II is capable of traveling to any on-set environment.

5″ 1920 x 1080 supports up to HD 4K video
500nit brightness
Wide color gamut
10bit (8+2FRC)
3D LUT support via USB input
Monitoring tools include focus peaking, false color, image flip, histogram, color temperature, custom RGB, and more
1000:1 Contrast Ratio

1 x Portkeys PT5 Monitor
1 x One micro-HDMI to full-size HDMI cable (HDMI A to D)
1 x One full-size HDMI to full-size HDMI cable (HDMI A to A)
1 x Monitor mount with a hex key
Sunhood brackets
A foldable sunshade
A warm prompt card
A printed user manual
A safety case

Basic Parameters: Screen Size 5″
Dimension 136*72*17mm
Viewing Angle 178°H/178°V
Brightness 500nit
Resolution 1920*1080
Contrast Ratio 1000:1
Weight 130g
Color Depth 10bit(8+2 FRC)
Power Consumption 7W
Material PC material with higher toughness, improved hardness, and strength.
Input Voltage 7.4~24V
Output Voltage 5V2A
Video Signal Input HDMI 4K30P
Video Signal Output HDMI 4K30P
USB-A Upgrade Firmware/Load LUT
